ZEBRONICS H61-NVMe Motherboard Full Specifications and Features.

Store Links

🔧 Category	📌 Specifications
🏷️ Brand	ZEBRONICS
📦 Model Name	H61-NVMe / H61 M2
🖥️ Form Factor	Micro-ATX
🌍 Country of Origin	China

🔌 CPU Socket	LGA 1155
🧠 Supported CPUs	Intel Core i7 / i5 / i3, Pentium, Celeron (2nd & 3rd Gen)
🧩 Chipset	Intel H61
💻 BIOS	AMI BIOS

🧮 Memory Slots	2 × DDR3 DIMM (Dual Channel)
📊 Max Memory Capacity	Up to 16 GB
⚡ Supported RAM Speed	DDR3 1066 / 1333 / 1600 MHz
🔁 Dual Channel Support	✅ Yes

🚀 M.2 Slot	1 × M.2 Slot
💽 SATA Ports	4 × SATA II (3 Gb/s)
🔄 USB Header	1 × USB 2.0 Header
🔋 Power Connector	24-Pin ATX + 4-Pin ATX 12V
🧪 CMOS Header	1 × 2-Pin CMOS Header
🧠 Debug Header	1 × Debug Card Header

🎮 PCIe Slot

1 × PCI Express 3.0 x16

🎥 HDMI Port	1
🖥️ VGA Port	1
🔌 USB Ports	6 × USB 2.0
🌐 LAN Port	1 × RJ-45
🔊 Audio Ports	1 × 3-in-1 Audio Jack

🔈 Integrated Audio	Stereo Audio
🌐 LAN Controller	Realtek 8106E
📡 LAN Speed	10/100 Mbps
🛜 Built-in Wi-Fi	❌ No (Requires external USB or PCIe adapters for wireless connectivity)
🔵 Built-in Bluetooth	❌ No (Requires external USB or PCIe adapters for wireless connectivity)

🌬️ Fan Connectors	2
🎧 Front Audio Connector	1
🔘 Front Panel Connector	1
🔔 Speaker Connector	1

📦 Package Contents

📦 Item	🔢 Quantity
🧩 Motherboard	1 Unit
🔌 SATA Cable	1 Unit
🛡️ I/O Backplate	1 Unit
💿 Driver Disc	1 Unit
📘 User Manual	1 Unit

ZEBRONICS H61-NVMe Motherboard Review: Best Budget LGA 1155 Motherboard in 2025?

If you are planning to build or upgrade a budget PC using Intel 2nd or 3rd Generation processors, finding a reliable motherboard can be challenging. The ZEBRONICS H61-NVMe Motherboard is one of the few newly available options for the LGA 1155 socket, offering modern features like an M.2 NVMe slot, HDMI output, and stable DDR3 memory support.

In this detailed review, we will explore the features, specifications, performance, pros & cons, and use cases of the ZEBRONICS H61-NVMe motherboard, helping you decide whether it’s the right choice for your PC build.

---

Overview of ZEBRONICS H61-NVMe Motherboard

The ZEB-H61 NVMe (H61 M2) motherboard is built around the Intel H61 Express chipset, designed specifically for Intel 2nd Gen (Sandy Bridge) and 3rd Gen (Ivy Bridge) processors. It supports DDR3 RAM up to 16GB, includes 4 SATA II ports, and stands out by offering an M.2 NVMe slot, which is rarely seen on H61 chipset motherboards.

This makes it an excellent option for users who want to revive older Intel systems with faster storage while keeping costs low.

Key Specifications at a Glance

• Socket: LGA 1155
• Chipset: Intel H61 Express
• Form Factor: Micro-ATX
• Memory Support: DDR3 (1066 / 1333 / 1600 MHz)
• Max RAM: 16GB
• Storage: 4 × SATA II + 1 × M.2 NVMe
• Expansion Slot: PCIe 3.0 x16
• Video Output: HDMI
• Audio: 5.1 Channel HD Audio
• LAN: 10/100 Mbps Ethernet
• Wi-Fi & Bluetooth: Not Available

CPU & Chipset Compatibility

The ZEBRONICS H61-NVMe motherboard supports a wide range of Intel LGA 1155 processors, including:

• Intel Core i3, i5, i7 (2nd & 3rd Gen)
• Intel Pentium
• Intel Celeron

Thanks to the Intel H61 chipset, the board delivers stable performance for everyday computing tasks such as office work, browsing, media consumption, and light gaming.

Although it does not support overclocking, it is perfectly optimized for stock CPU performance and long-term reliability.

---

Memory Support & Performance

This motherboard supports DDR3 RAM up to 1600 MHz, with a maximum capacity of 16GB across 2 DIMM slots. This is more than sufficient for:

• Windows 10 / Windows 11 (with compatible CPU)
• Multitasking
• Light photo & video editing
• Office and educational use

For best performance, using dual-channel DDR3 memory is recommended.

Storage Options: SATA + M.2 NVMe Advantage

One of the biggest highlights of the ZEBRONICS H61-NVMe motherboard is the inclusion of an M.2 NVMe slot.

Storage Features:

• 4 × SATA II ports for HDDs and SATA SSDs
• 1 × M.2 NVMe slot for faster boot and load times

This feature allows users to significantly improve system responsiveness compared to traditional SATA-only H61 motherboards. Installing an NVMe SSD can drastically reduce boot times and application loading speeds.

⚠️ Note: Performance may be limited by chipset and PCIe lanes, but it is still much faster than SATA SSDs.

Graphics & Expansion Support

The motherboard comes with a PCI-Express 3.0 x16 slot, enabling support for dedicated graphics cards such as:

• NVIDIA GT series
• GTX 700 / 900 series
• AMD Radeon RX 500 series (CPU dependent)

It also includes HDMI output, making it easy to connect modern monitors and TVs using integrated graphics from supported Intel CPUs.

This makes the board suitable for basic gaming, multimedia PCs, and HTPC builds.

Audio & Networking

🔊 Audio

• Supports 5.1 Channel HD Audio
• Suitable for movies, music, and casual gaming

🌐 Networking

• RJ-45 Ethernet port (10/100 Mbps)
• Stable wired internet connectivity

❌ No built-in Wi-Fi or Bluetooth, so users will need:

• USB Wi-Fi adapter or
• PCIe network card (if slot available)

Build Quality & Design

ZEBRONICS has designed the H61-NVMe motherboard with solid PCB quality, clean layout, and proper spacing for components. The Micro-ATX form factor ensures compatibility with most standard PC cabinets.

With a weight of 510 grams and standard 24-pin ATX power connector, installation is straightforward even for beginners.

Pros and Cons

✅ Pros

• Supports Intel 2nd & 3rd Gen CPUs
• Rare M.2 NVMe slot on H61 chipset
• HDMI output for modern displays
• DDR3 RAM up to 16GB
• Budget-friendly option
• Ideal for upgrading old systems

❌ Cons

• No built-in Wi-Fi or Bluetooth
• Limited to SATA II speeds
• No USB 3.0 support
• No CPU overclocking support

Best Use Cases

The ZEBRONICS H61-NVMe motherboard is best suited for:

• 💻 Budget PC builds
• 🔄 Upgrading old LGA 1155 systems
• 🏢 Office & educational computers
• 🎬 Home theater PCs (HTPC)
• 🧑‍💻 Daily productivity & browsing

It is not recommended for high-end gaming or professional workloads that require newer CPUs and faster interfaces.

Final Verdict: Is ZEBRONICS H61-NVMe Motherboard Worth Buying?

If you are looking for a reliable, affordable motherboard for Intel LGA 1155 processors, the ZEBRONICS H61-NVMe Motherboard is an excellent choice. The addition of an M.2 NVMe slot, HDMI output, and decent expansion support makes it stand out from traditional H61 boards.

While it lacks modern features like Wi-Fi, Bluetooth, USB 3.0, and overclocking, it delivers great value for money for users who want to extend the life of older Intel systems.
